MAS for advanced system
Model Name/Number IDP-CONTROL
Type Addressable
Minimum Order Quantity 1
Brand Honeywell
Description
IDP-CONTROL Addressable Notification Module The IDP-CONTROL is an addressable notification module for use with Honeywell Farenhyt Series fire alarm control panels (FACPs). The IDPCONTROL gives you the flexibility to add notification circuits wherever they are needed on an Farenhyt FACP signaling line circuit (SLC) loop. The IDP-CONTROL provides supervised monitoring of wiring to load devices that require an external power supply to operate, such as bells, horns, and strobes. It is capable of Class B and Class A supervision. Upon command from the FACP, the IDP-CONTROL will disconnect the supervision and connect the external power supply across the load device. The disconnection of the supervision provides a positive indication to the panel that the control relay actually turned on. The external power supply is always relay isolated from the SLC loop, so that a trouble condition on the power supply will never interfere with the rest of the system.
INSTALLATION The IDP-CONTROL
mounts directly into a 4” square electrical box. The box must have a minimum depth of 2-1/8”. A surface mount electrical box (System Sensor® PN SMB500) is available from Honeywell.
COMPATIBILITY The IDP-CONTROL is compatible with the following Farenhyt Series FACPs: • IFP-2100 / IFP-2100ECS / RFP-2100 • IFP-2000 / IFP-2000ECS / RPS-2000 • IFP-1000 / IFP-1000ECS • IFP-300 / IFP-300ECS • IFP-100 / IFP-100ECS • IFP-75 • IFP-50
ماركة / براند | HONEYWELL |
تكلفة الشحن |
|
موعد التسليم | جاهز للشحن في 2-3 أيام عمل |
موقع المتجر | 28 متولي الشعراوي امتداد مهدي عرفة بجوار مستشفى الماسة الحي العاشر مدينة نصر, Cairo, Egypt |
